ND30-09D 27 User's manual
08 L1 phase voltage THD*
THD U1
%
09 L1 phase current THD
THD I1
%
10 L2 phase voltage
U2
(M,k)V
x x
11 L2 phase wire current
I2
(k)A
x
12 L2 phase active power
P2
(G, M, k)W
x x
13 L2 phase reactive power
Q2
(G, M, k)var
/
x x
14 L2 phase apparent power
S2
(G, M, k)VA
x x
15 L2 phase active power factor
(PF2=P2/S2)
PF2
PF
x x
16
tg factor of L2 phase
(tg2=Q2/P2)
tg2
x x
17 L2 phase voltage THD*
THD U2
%
x
18 L2 phase current THD
THD I2
%
x
19 L3 phase voltage
U3
(M,k)V
x x
20 L3 phase wire current
I3
(k)A
x
21 L3 phase active power
P3
(G, M, k)W
x x
22 L3 phase reactive power
Q3
(G, M, k)var
/
x x
23 L3 phase apparent power
S3
(G, M, k)VA
x x
24 L3 phase active power factor
(PF3=P3/S3)
PF3
x x
25 tg factor of L3 phase
(tg3=Q3/P3)
tg3
x x
26 L3 phase voltage THD*
THD U3
V%
x
27 L3 phase current THD
THD I3
A%
x
28 mean phase voltage
U avg
(M, k)V
x x
29 mean 3-phase current
I avg
(k)A
x
30 3-phase active power
P
(G, M, k)W +/-
31 3-phase reactive power
Q
(G, M, k)var
/
32
3-phase apparent power
S
(G, M, k)VA
33 active power factor 3-phase
(PF=P/S)
PF avg
x
34
tg factor average for 3
phases (tg=Q/P)
tg avg
x
35
THD U mean 3-phase*
THD U
%
x
36
THD I mean 3-phase
THD I
%
x
37
frequency
f
Hz
38
phase-to-phase voltage L1-L2
U12
(M,k)V
x
39
phase-to-phase voltage L2-L3
U23
(M,k)V
x
40
phase-to-phase voltage L3-L1
U31
(M,k)V
x
