ND30-09D 71 User's manual
6100/8100 7550 R
Reactive 3-phase inductive
energy (counter counting up to
99999.99 kVArh)
kVA
rh
6102/8102 7551 R
Reactive 3-phase capacity
energy (no. of register 7552
overflows, resets to 0 after
reaching 9999.9 MVArh)
100
MV
Arh
6104/8104 7552 R
Reactive 3-phase capacity
energy (counter counting up to
99999.99 kVArh)
kVA
rh
6106/8106 7553 R
Apparent energy
(no. of
register 7554 overflows, resets
to 0 after reaching 9999.9
MVAh)
100
MV
Ah
6108/8108 7554 R
Apparent energy
(counter
counting up to 99999.99 kVAh)
kVA
h
6110/8110 7555 R Time – seconds sec
6112/8112 7556 R Time – hours, minutes
6114/8114 7557 R Date – month, day
6116/8116 7558 R Year – 2014 - 2100
6118/8118 7559 R Status 1 register -
6120/8120 7560 R Status 2 register -
6122/8122 7561 R Status 3 register -
6124/8124 7562 R Status 4 register -
6126/8126 7563 R Status 5 register -
6128/8128 7564 R Status 6 register -
6130/7130 7565 R Continuous output 1 activation mA
6132/8132 7566 R Temperature Pt100 1
C
6134/8134 7567 R Temperature Pt100 2
C
6136/8136 7568 R Voltage L1 min V
x
6138/8138 7569 R Voltage L1 max V
x
6140/8140 7570 R Voltage L2 min V
x x
6142/8142 7571 R Voltage L2 max V
x x
6144/8144 7572 R Voltage L3 min V
x x
6146/8146 7573 R Voltage L3 max V
x x
6148/8148 7574 R Current L1 min A
x
6150/8150 7575 R Current L1 max A
x
6152/8152 7576 R Current L2 min A
x
6154/8154 7577 R Current L2 max A
x
6156/8156 7578 R Current L3 min A
x
6158/8158 7579 R Current L3 max A
x
6160/8160 7580 R Active power L1 min W
x
6162/8162 7581 R Active power L1 max W
x
6164/8164 7582 R Active power L2 min W
x x
6166/8166 7583 R Active power L2 max W
x x
6168/8168 7584 R Active power L3 min W
x x
6170/8170 7585 R Active power L3 max W
x x
