ND30-09D 70 User's manual
6048/8048 7524 R
tgφ factor of L3 phase
(tg3=Q3/P3)
-
x x
6050/8050 7525 R THD U3* %
x
6052/8052 7526 R THD I3 %
x
6054/8054 7527 R Mean 3-phase voltage V
x x
6056/8056 7528 R Mean 3-phase current A
x
6058/8058 7529 R
3-phase active power
(P1+P2+P3)
W
x
6060/8060 7530 R
3-phase reactive power
(Q1+Q2+Q3)
VAr
x
6062/8062 7531 R
3-phase apparent power
(S1+S2+S3)
VA
x
6064/8064 7532 R
3-phase active power factor
(PF=P/S)
-
x
6066/8066 7533 R
Mean tg factor φ for 3 phases
(tg=Q/P)
-
x
6068/8068 7534 R THD U* mean 3-phase %
x
6070/8070 7535 R THD I mean 3-phase %
x
6072/8072 7536 R Frequency f
6074/8074 7537 R Phase-to-phase voltage L
1-2
V
x
6076/8076 7538 R Phase-to-phase voltage L
2-3
V
x
6078/8078 7539 R Phase-to-phase voltage L
3-1
V
x
6080/8080 7540 R Mean phase-to-phase voltage V
x
6082/8082 7541 R
Active power averaged
(P Demand)
W
x
6084/8084 7542 R
Reactive power averaged
S Demand )
VA
x
6086/8086 7543 R Current averaged (I Demand) A
x
6088/8088 7544 R
Neutral wire current
(calculated from vectors)
A
x x
6090/8090 7545 R
Active 3-phase import energy
(no. of register 7546 overflows,
resets to 0 after reaching
9999.9 MWh)
100
MW
h
6092/8092 7546 R
Active 3-phase import energy
(counter counting up to
99999.99 kWh)
kWh
6094/8094 7547 R
Active 3-phase export energy
(no. of register 7548 overflows,
resets to 0 after reaching
9999.9 MWh)
100
MW
h
6096/8096 7548 R
Active 3-phase export energy
(counter counting up to
99999.99 kWh)
kWh
6098/8098 7549 R
Reactive 3-phase inductive
energy (no. of register 7550
overflows, resets to 0 after
reaching 9999.9 MVArh).
100
MV
Arh
