ND30-09D 69 User's manual
Status 7 register –(address 4424, R)
Bit 8 – reserved
Bit 7 – reserved
Bit 6 – reserved
Bit 5 – reserved
Bit 4 – reserved
Bit 3 – reserved
Bit 2 – reserved
Bit 1 – „1” – function of MQTT protocol enabled
Bit 0 – „1” – function of supervisory relay enabled
Table 21
16-bit
register
address
2x16 1032/
2x16 3210
Register
address
32-bit
Operati
ons
Description Unit
3Ph
/
4W
3Ph
/
3W
1Ph
/
2W
6000/8000 7500 R L1 phase voltage V
x
6002/8002 7501 R L1 phase current A
6004/8004 7502 R L1 phase active power W
x
6006/8006 7503 R L1 phase reactive power VAr
x
6008/8008 7504 R L1 phase apparent power VA
x
6010/8010 7505 R
L1 phase active power factor
(PF1=P1/S1))
-
x
6012/8012 7506 R
tgφ factor of L1 phase
(tg1=Q1/P1)
-
x
6014/8014 7507 R THD U1* %
x
6016/8016 7508 R THD I1 %
x
6018/8018 7509 R L2 phase voltage V
x x
6020/8020 7510 R L2 phase current A
x
6022/8022 7511 R L2 phase active power W
x x
6024/8024 7512 R L2 phase reactive power VAr
x x
6026/8026 7513 R L2 phase apparent power VA
x x
6028/8028 7514 R
L2 phase active power factor
(PF2=P2/S2)
-
x x
6030/8030 7515 R
tgφ factor of L2 phase
(tg2=Q2/P2)
-
x x
6032/8032 7516 R THD U2* %
x
6034/8034 7517 R THD I2 %
x
6036/8036 7518 R L3 phase voltage V
x x
6038/8038 7519 R L3 phase current A
x
6040/8040 7520 R L3 phase active power W
x x
6042/8042 7521 R L3 phase reactive power VAr
x x
6044/8044 7522 R L3 phase apparent power VA
x x
6046/8046 7523 R
L3 phase active power factor
(PF3=P3/S3)
-
x x
