User Manual CANopen/EtherCAT
14
Example of the flash sequence:
ER > 02 > 05 * ER > 02 > 05 ...
Error: ER = “Fault“
Error name: 02 = “Error in the parameter list“
Description of error: 05 = “Function for checking current parameter list“
2.5 Hardware enable
ServoOne has a control input for ENPO hardware enable on the control terminal.
This input must be configured to operate the power stage at 24 V.
The device also provides the function “STO (Safe Torque Off)“ (see Operation Manual or
Application Manual ServoOne), category 3, control terminal ISDSH. For these devices the
relevant function logic must be implemented by way of the higher-order controller as
per the Application Manual.
Note: Without configuration of the inputs ENPO and ISDSH the device stays
in state 1 = “Not Ready to Switch On“ or 2 = “Switch On Disabled“.
Only after correct configuration can the state be exited by a “Shutdown“
command via bus.
�
