User Guide
12
© Copyright 2011 Luxul. All rights reserved. Trademarks & Registered Trademarks are property of respective holders.
4.4 Network Transmission Media
For the RJ-45 ports, Category-5, super Category-5 or Category-6 unshielded twisted
pair (CAT5/CAT5e/CAT6 UTP) should be used. For best results, it is recommended
that Category-6 shielded twisted pair be used to ensure stable data transmission at
1000 Mbps. Optical fi ber/cable should be selected based on the wavelength of the
SFP optical module to be used.
CAUTION: Make sure only one Uplink channel exists between switches
or between the XMS-1008P and a router. Otherwise, loops
can occur and result in network failure.
5 CONFIGURATION
5.1 Login
The XMS-1008P is not equipped with internal DHCP server. However, if you are
connecting to the XBR-2300 Enterprise Dual-WAN Router with the default LAN
address, the confi guration will be automatic. Otherwise, the IP address of the
computer for login and confi guration will need to be manually confi gured. The
table below lists the default parameters of the XMS-1008P.
Parameter: Default Value
Default IP address:
192.168.0.3
Default user name:
admin
Default password:
admin
Login to the switch with the following steps:
1. Plug an Ethernet cable into any of the switch ports
2. Plug the other end into the Ethernet port of your computer
3. Power on the switch.
4. Check to see that the IP address of the computer is within this network seg-
ment: 192.168.0.xxx (“xxx” ranges 2~254. For example, 192.168.0.50). For IP address
settings, refer to Appendix 2.
5. Open the Web browser and enter 192.168.0.3. The switch login window appears,
as shown below.
