User Guide
6
© Copyright 2011 Luxul. All rights reserved. Trademarks & Registered Trademarks are property of respective holders.
Quality of Service
(QoS)
4 Queues per port
Queue handling: Strict, Weighted Round Robin (WRR)
CoS based on DCSP, 802.1P and Port-based Priority Queues
Port based bandwidth control
Access
Control
List
Maximum profi les: 50
Maximum rules shared by profi les: 240
ACL based on MAC address, IPv4 Address, VLAN ID, 802.1p
Priority, DSCP
ACL actions: permit, deny
Security
802.1X Port Based Access Control: Default forwarding
Port Security: Supports up to 64 MAC addresses per port
Traffi c Control: Broadcast/multicast/unicast storm control
Static MAC: Supports 256 Static MAC entries
Management Features
Web Based GUI
System Log: Max 500 log entries
Network Data Transfer
Rate
Ethernet: 10Mbps (Half-duplex)
Ethernet: 20Mbps (Full-duplex)
Fast Ethernet: 100Mbps (Half-duplex)
Fast Ethernet: 200Mbps (Full-duplex)
Gigabit Ethernet: 1000Mbps (Half-duplex)
Gigabit Ethernet: 2000Mbps (Full-duplex)
Interface Options
RJ-45:
10BASE-T: Cat.5 UTP/STP
100BASE-TX: Cat.5 UTP/STP
1000BASE-T: Cat.5, Cat.5e, or Cat.6 UTP/STP
Gigabit fi ber/copper uplinks on SFP ports
Cable Recognition for Straight-through or Crossover
Cables
Certifi cations
FCC Class A, CE, RoHS
LED
Per unit: Power
Per port: Link/Activity, 1000mbps, POE
Power Consumption
120 Watts Maximum (POE Full Run)
Power Supply
Internal Switched Power, AC 100-240V, 50-60Hz input
Operating Temperature
32°F to 104ºF (0°C to 40°C)
Operating Humidity
10% to 90% (Non-condensing)
Dimensions
W x D x H:
17.3”(439.5mm) x 8.3”(211mm) x 1.7”(43.2mm)
