Port Status
Indicates the Port is not connected to a device.
Indicates the Port is connected at the speed of 1000Mbps.
Indicates the Port is connected at the speed of 10Mbps or 100Mbps.
Indicates the SFP Port is not connected.
Indicates the SFP Port is connected at the speed of 1000Mbps.
Indicates the SFP Port is connected at the speed of 100Mbps.
When the cursor is used to highlight the Port, the detailed information of the Port will
be displayed.
Figure 4-2 Port Information
Port Information
Port:
Displays the selected Port number of the Switch.
Type:
Displays the confi gured type of the Port
Speed:
Displays the maximum transmission rate of the Port.
Status:
Displays the connection status of the Port.
