214683 350 Revision A
Figure 4.91: Driveline
12. Detach safety chain (C) from support bracket (B)
13. Pull collar (D) back to release driveline (A) from support
bracket. Remove the driveline from the support bracket.
Figure 4.92: Driveline
14. Pull back the collar (A) on the end of the driveline, and
push the driveline onto the combine output shaft (B)
until the collar locks.
HEADER ATTACHMENT/DETACHMENT
