MacDon R113 - Page 19

214633 7 Revision C
Ref
Part
Number Description Qty
1
NSS
1
ASSEMBLY – TRANSPORT WHEEL FRAME
1
2 NSS
1
ASSEMBLY – PIN TRANSPORT
1
3 NSS
1
ASSEMBLY – TRANSPORT VALVE MOUNTING
1
4
247958 BRACKET - SUPPORT
1
5
223185 ASSEMBLY – SUPPORT, DUAL LAMP, LH
1
6 259218 BRACKET – SMV, SIS SIGN
1
7
NSS
1
ASSEMBLY – CYL, 3.5" TRANSPORT
1
8 136325 CAP - HYD SAE -6 ORFS 2
9 NSS
1
ASSEMBLY – TONGUE-HITCH LATCH
1
10 NSS
1
ASSEMBLY – TRANSPORT SWING COMPLETE 1
11 247625 ASSEMBLY – TRANSPORT COMPLETE PADDLE 1
12 247106 HOSE - HYD 1
13 224162 HOSE - HYD
1
14
224160 HOSE - HYD
1
15
247335 LINE - HYDRAULIC
1
16 246954 LINE - HYDRAULIC
1
17
247781 HOSE - HYD 2
18 246366 HOSE - HYD 2
19 136326 PLUG - HYD SAE -6 ORFS 2
20 NSS
1
ASSEMBLY – COVER WITHOUT MODULE
1
21 281614 HARNESS - TRANSPORT LIGHTS
1
22 NSS
1
WHEEL ASSEMBLY - SILVER 2
23 NSS
1
CONNECTOR - AT06-2S-SS01, SOLID
1
24 30753
2
FASTENER - CABLE TIE BLACK
3
ATTACHED TO ASSEMBLY — PIN TRANSPORT:
A
136157 BOLT - HEX HD M20X2.5X65-10.9-AA1J 5
B
112130
WASHER - HARD ASTM F436 3/4-400HV-AB3C
5
C
136122 NUT - HEX FLG CTR LOC M20X2.5-10-AA1J 5
PARTS LIST
1. Not sold seperately.
2. Ties are attached to hoses MD #246366.
