MacDon R113 - Page 74

214633 62 Revision C
1023663
A
B
Figure 6.1: Rotary Disc Pull-Type Hitch – Model Year
2018 and Prior
1026348
A
B
Figure 6.2: Rotary Disc Pull-Type Hitch – Model
Year 2019
1030361
AB
Figure 6.3: Rotary Disc Pull-Type Hitch – Model Year
2020 and Later
1. Remove lynch pin (A) from clevis pin (B), and remove the
clevis pin from the rotary disc pull-type hitch.
REFERENCE
