MacDon R113 - Page 75

214633 63 Revision C
1030439
A
B
Figure 6.4: Rotary Disc Pull-Type Hitch
1026349
A
B
Figure 6.5: Rotary Disc Pull-Type Hitch
1030363
A
B
Figure 6.6: Rotary Disc Pull-Type Hitch – Model Year
2020 and Later
2. Move the tractor to position drawbar hitch adapter (A)
under pin (B) in the hitch. Adjust height as necessary
with jack.
3. Shut down the engine, and remove the key from
the ignition.
REFERENCE
