MacDon R113 - Page 77

214633 65 Revision C
1010735
A
B
C
D
Figure 6.10: Primary Driveline – Model Year 2018
and Prior
1026351
AB
C
D
Figure 6.11: Primary Driveline – Model Year 2019
1030357
A
B
C
D
Figure 6.12: Primary Driveline – Model Year 2020
and Later
6. Position primary driveline (A) onto the tractor power take-
off (PTO).
7. Pull back collar (B) on driveline (A), and push the driveline
until it locks. Release collar.
8. Route safety chain (C) from the rotary disc pull-type
through chain support (D) on the drawbar hitch adapter
and around the tractor drawbar support. Lock hook
on chain.
IMPORTANT:
If the tractor has a three-point hitch, lift the links as far as
possible to prevent damage to the hitch.
