214633 71 Revision C
For model year 2020 and later:
CAUTION
Check to be sure all bystanders have cleared the area.
Figure 6.26: Hitch Stand in Working Position
16. Clear bystanders from the area and start the tractor. Do
NOT operate the pull-type.
17. Raise the hitch so that stand (A) is off the ground.
18. Shut down the engine, and remove the key from
the ignition.
19. Remove inner hairpin (B) to release stand (A).
Figure 6.27: Repositioning Hitch Stand
20. Rotate stand (A) upward and into storage position.
Figure 6.28: Hitch Stand in Storage Position
21. Insert pin (A) and secure stand (B) in storage position.
REFERENCE
