214633 70 Revision C
For model year 2019 and prior:
CAUTION
Check to be sure all bystanders have cleared the area.
Figure 6.23: Hitch Stand
10. Clear bystanders from the area and start tractor. Do NOT
operate the rotary disc pull-type.
11. Start the tractor and raise the hitch so that stand (A) is off
the ground.
12. Shut down the engine, and remove the key from
the ignition.
13. Remove inner hairpin (B) and pull lock (C) to release
stand (A).
Figure 6.24: Hitch Stand
14. Raise stand (A), rotate lock (B) clockwise to vertical
position, and re-engage lock (B) to hold the stand in the
storage location.
Figure 6.25: Hitch Stand
15. Secure lock with lynch pin (A).
