Magellan GPS ColorTRAK User Manual

16 Magellan GPS ColorTRAK
Using the Position Screen
The POSITION screen displays the coordinates of your last computed
position and basic navigation data. You also have the option of viewing your
present position using another coordinate system.
Viewing Secondary Coordinate System from the POSITION Screen
Press the LEFT/RIGHT ARROWs and the
lower half of the screen changes to display
your present position in secondary coordinate
system. The datums that have been selected
under SETUP for each coordinate system are
also displayed. In the example shown, we are
using the WGS84 datum for our LAT/LON
coordinates and NAD27 datum for the UTM
coordinates.
Automatic Averaging in the POSITION Screen
Automatic averaging gives you greater position accuracy. When navigating,
your GPS ColorTRAK takes position fixes, however, when you are station-
ary, at zero speed, the receiver begins averaging mode. Once you begin
moving, position averaging ends and the receiver begins displaying instanta-
neous position fixes while you navigate.
Current Time
Current Date
Position
Coordinates
Current
Elevation
Current Speed
Estimated Position
Error (may display
DGPS or Simulate)
Compass
Course
Distance Travelled
Position Icon
Second Coordinate
System access
LAT/LON
N
34 ˚ 06.52
117˚49.56
W
900 FT
11:23:35 PM
EPE 112 FT
23JAN97
WGS84
UTM
NAD27
23
11 4 760W
74
37
479N
150
120 S
K
T
n
m
m
POSITION
N
34˚06.52
117˚49.56
W
ELEV 900 FT
11:23:35 PM
SPEED
5.38
EPE 112 FT
TRIP
238.8
COURSE 150
23JAN97
°
