Antenna Removal
Antenna Removal. The GPS ColorTRAK has a quadrifilar antenna
that can be removed. The antenna may be removed in order to connect an
external antenna.
To remove the antenna, hold the receiver in one hand and rotate the antenna
to the stop at the 1 o’clock position (as shown below). Firmly grip the
antenna with the other hand and pull the antenna from the receiver.
To replace the antenna. Remove any external antenna that you have
connected. Place the antenna at the 1 o’clock position and connect the
antenna to the receiver.
Turn to
stop at
1 o’clock
Pull to remove
from receiver
GPS ColorTRAK
