Magic Vac Jumbo - Appliance Parts Names

21
APPLIANCE PARTS NAMES
(2)
(3)
(4)
(1)
(5)
(6)
(9)
(11)
(10)
(10A)
(12)
(7)
(9)
(8)
(13)
(1) ON (I)-OFF (0)switch - Press (I) to turn on the
appliance,keeptheswitchonOFF(0)whenyouare
notusingit.
(2) Controlskeyboard-Forsettingthemanyfunctions
of the appliance ( ).
(3) Vacuum gauge - Mechanically-operated analogue
instrumentindicatingthevacuumvalueobtained.
(4) Hose air inlet - Forconnectingthehosetocreate
the vacuum in MAGIC VAC
®
Executive containers, in
containers sealed with MAGIC VAC
®
Universal Caps,
in bottles using MAGIC VAC
®
 Bottle Caps and in
glassjarswithlidandring.
(5) Lid - Opening the lid intothe xed raisedposition
allowsyoutopositionthebagsbeforestartingthe
vacuumpackingprocess.
(6) Lidhandle-It makes it easier to close the lid before
startingthepackingcycle.
(7) Patented “Lock&Unlock System” -It locks and
releases the bag introduction area, to perform an
automaticpackingcycleandreducehands-ontime.TheLock&UnlockSystemisttedwithagasspringforgentle
lidopening.
(8) Sealinggasket-Itpressesthebagagainstthesealingbar.
(9) Airtightgaskets-Theyguaranteethatavacuumwillbemaintainedinthechamber,thusallowingairtoberemoved
from MAGIC VAC
®
bags.
(10)Vacuumchamberwithpull-outtray-Forbagpositioningandairremoval;insidethevacuumchambertheliquid-
proof tray is placed (10A)whichisremovableandwashablealsoindishwasherformaximumhygiene.
(11)Sealingbarwithheavy-dutycoolingsystem-Heatingelementthatsealsthebagandpreventsitfromstickingto
the bar.
(12)Powderfoodstuffslter-Preventspowderfoodstuffs(sugar,our,coffee,etc.)fromenteringthepumpandcausing
damage;itcanberemovedforeasycleaning.Theliquid-collectingtray(10A)shouldbepulledoutbeforeremoving
the filter.
(13)Non-slipfeet-Theypreventtheappliancefromslippingduringuse.
(14)Powersupplycord-Forconnectingtheappliancetothemainsvoltage.
