2. LIQUID CRYSTAL DISPLAY WITH TOUCHSCREEN
3. SPIN AND CONFIRM BUTTON AND NETWORK POWER INDICATOR
4. ARTICULATED ARM
5. NEBULIZER / TGI
6. INSPIRATORY LIMB CONNECTOR
7. EXHALATION VALVE AND DISTAL FLOW SENSOR
8. DISTAL FLOW SENSOR CABLE CONNECTOR
9. CARRYING STRAP
10. PEDESTAL
11. CASTORS WITH BRAKES
Back View
Figure 2 – Back View
1. On/Off Switch
2. Input of Electrical Power
3. Fuse holder
4. Inlet of Compressed Air
5. Inlet of Oxygen
6. Collectors of Water with Coalescing Filter for Gas under High Pressure
7. Inlet for Power External Source
