Appendix – Spare Parts List
163
Description
Pictorial
Reference
Drive
Rating
Reference
Designator
Magnetek kit
Number
Quantity
Per
Drive
DC Output Contactor (110V
coil)
Motor Armature Contactor
(ME), 120V coil option. If
used must also use the
46S04174-0020 A8 PCB
Use with single and dual
contactor configurations
125A ME LA05P00032-0177 1
150A
ME
LA05P00032-0177 1
200A
ME
LA05P00032-0177 1
250A
ME
LA05P00031-0152 1
300A
ME
LA05P00032-0220 1
DC Output Contacto
r
(240V
coil)
Motor Armature Contactor
(ME)
Use only with single
contactor configurations
125A ME LA05P00032-0154 1
150A
ME
LA05P00032-0154 1
200A
ME
LA05P00032-0154 1
250A
ME
LA05P00032-0155 1
300A
ME
LA05P00032-0156 1
DC Output Contactor (240V
coil)
Motor Armature Contactor
(ME)
Use only with Dual
contactor configurations
125A ME1A,ME1B LA05P00032-0258 2
150A
ME1A,ME1B
LA05P00032-0258 2
200A
ME1A,ME1B
LA05P00032-0258 2
250A
ME1A,ME1B
LA05P00032-0259 2
300A
ME1A,ME1B
LA05P00032-0210 2
Contact kits – 2 Pole N.O.
ABB220
05P00066-0700 1
ABB280
05P00066-0701 1
ABB360
05P00066-0702 1
Contact kits – DB Pole N.C. ABB220
05P00066-0703 1
ABB280
05P00066-0704 1
ABB360
05P00066-0705 1
DC Output Contactor
Auxiliaries
(1NO 13,14 / 1NC 21,22)
ALL 1M AUX LA05P00054-0239 1
DC Output Contactor
Auxiliaries
(2NO 43,44 / 2NC 31,32)
ALL 1M AUX LA05P00054-0240 1
DC Output Contactor Coils
ABB220,280 120Vac
125A-
250A
1M Coil,
120Vac
LA05P00032-0206 1
DC Output Contactor Coils
ABB220,280 240Vac
125A-
250A
1M Coil,
240Vac
LA05P00032-0207 1
DC Output Contactor Coil
ABB360 120Vac
300A
1M Coil,
120Vac
LA05P00032-0221 1
