Magnetic MGCplus User Manual

54
Control unit MGCplus
Description of menus and parameters
Operational view > Main menu > Settings > Signalling > GED no. 1 / GED no. 2
Parameter Description
Validation response
(Signalling hold-
open time end)
Select the GED behaviour when the set hold-open time is below a certain
value.
The special signalling should encourage a person to move on.
Options
› Off: No special signalling
› Variant 1: If the hold-open time is less than 7 seconds, the GED will flash
green at 1.7 Hz.
› Variant 2: If the hold-open time is less than 7 seconds, the GED will flash
green. The flashing frequency changes depending on the hold-open time:
< 7 seconds 1 Hz, < 5 seconds 1.7 Hz, < 2 seconds 5 Hz
Factory setting
› Variant 2:
On intrusion Select the display pattern for the "On intrusion" event.
Options
ä Page 55, section "Display pattern on the GED".
Factory setting
› Pulse red 2.5 Hz
On wrong direction Select the display pattern for the "On wrong direction" event.
Options
ä Page 55, section "Display pattern on the GED".
Factory setting
› Toggle red/green 2.5 Hz
On tailgating Select the display pattern for the "On tailgating" event.
Options
ä Page 55, section "Display pattern on the GED".
Factory setting
› Double pulse short red
On emergency Select the display pattern for the "On emergency" event.
Options
ä Page 55, section "Display pattern on the GED".
Factory setting
› Double pulse short green
On error Select the display pattern for the "On error" event.
Options
ä Page 55, section "Display pattern on the GED".
Factory setting
› Pulse red 1 Hz
Table 30: GED no. 1 / GED no. 2
