55
Control unit MGCplus
Description of menus and parameters
Display pattern on the GED
Option Description
Off No special display pattern for this state.
Dark GED switched off
Red GED shows a red cross.
Green GED shows a green arrow.
Pulse red 1 Hz GED flashes in red with a frequency of 1 Hz.
Pulse green 1 Hz GED flashes in green with a frequency of 1 Hz.
Pulse red 2.5 Hz GED flashes in red with a frequency of 2.5 Hz.
Pulse green 2.5 Hz GED flashes in green with a frequency of 2.5 Hz.
Pulse red 5 Hz GED flashes in red with a frequency of 5 Hz.
Pulse green 5 Hz GED flashes in green with a frequency of 5 Hz.
Double pulse short red GED flashes in red twice every second with a pulse of 100 ms.
Double pulse short green GED flashes in green twice every second with a pulse of 100 ms.
Toggle red/green 1 Hz GED toggles between red and green with a frequency of 1 Hz.
Red and green are each displayed for 500 ms.
Toggle red/green 2.5 Hz GED toggles between red and green with a frequency of 2.5 Hz.
Red and green are each displayed for 200 ms.
Toggle red/green 5 Hz GED toggles between red and green with a frequency of 5 Hz.
Red and green are each displayed for 100 ms.
Table 31: Display pattern on the GED
