7
-2
DIESEL ENGINE
SPECIFICATIONS
DESCRIPTION UNIT 3C093LWS 3C093LWG 3C100LWS 3A139LWS
POWER(Gross) HP (kw) 19 (14.2) 21 (15.7) 22 (16.4) 28 (20.9)
Rated revolution rpm 2,800 3,600 2,800 2,600
Maximum bare speed rpm 3,000 3,690 3,000 2,800
Minimun bare idling speed rpm 1,050 1,050 1,050 1,000
Type Vertical, water cooled, 4-cycle diesel engine
Number of cylnders 3
Total displacement cc (cu) 927 (56.6) 927 (56.6) 1,007 (61.5) 1,393 (84.9)
Turbocharger
----
Bore and stroke mm (in) Ø 75x70 (2.95x2.76) Ø 75x70 (2.95x2.76) Ø 75x76 (2.95x2.99) Ø 80x92.4 (3.15x3.6)
Method of Combustion Vortex chamber
Compression ratio 22:1 22:1 21:1 22:1
Injection timing BTDC 18° BTDC 24° BTDC 18° BTDC 18°
Injection order 1-2-3
Injection pressure kPa (kgf/㎠) 14710-15690kPa (150~160kgf/㎠)
Intake, exhaust clearance mm Intake: 0.15 Exhaust: 0.15 Intake: 0.25 Exhaust: 0.30
Direction of rotating Counter-clockwise (view from fl ywheel side)
