Two switches operate the independent PTO.
1. PTO ON/OFF SWITCH: PTO ON/OFF switch is
located on the LHS. on the steering column and can be
identified easily with its built in red colored indicator.
When the switch is pushed down to start the PTO
indicator glows to
indicate that the switch and the PTO are in ON position,
If the switch is pushed down again the indicator goes off
signaling that the PTO is OFF.
2. PTO Control SWITCH: This switch is located
near the starting key location on the dash panel. There are
three positions marked for this switch.
■
OFF at the center
■
■■
■
MANUAL at the left
■
■■
■
AUTO AT THE RIGHT.
The PTO shaft will not rotate if either of the two switches is in OFF position.
The following table explains how the PTO operates at the two
different (Manual & Auto) positions of the PTO Control switch
with the PTO ON/OFF switch in the on position.
PTO monitor Lamp
■
Engaging Cruise Control
DO NOT engage cruise control when reversing.
Engage the cruise control as follows:
– Depress the forward speed control pedal until the
required speed is achieved.
– Press the cruise control switch to engage cruise control.
– Release the forward speed control pedal.
■
Disengaging Cruise Control
To disengage the cruise control you can either press the
cruise control switch or depress the Master brake pedal.
►
►►
►
CRUISE CONTROL LMAP
►
►►
►
PTO MONITOR LAMP
■
THE PTO MONITOR LAMP on the dash panel indicates the state of the PTO shaft.
1. If the monitor glows: The PTO is rotating
2. If the monitor is off: The PTO is off
3. If the monitor blinks: The PTO is presently stationary but will instantly
start rotating when implements lowered.
