► STEERING
Ensure that the steering wheel does not have excessive free play.
►
►►
► BRAKE
Ensure that the left and right brakes are adjusted correctly so they operate simultaneously. The
correct free play on the brake is 1.18-1.57 in (30~40 mm).
►
►►
► ELECTRICAL
Check the operation of all gauge, switches, horn, lights and indicators.
►
►►
► INSTALLING LOADER
1.Connect P port of loader control valve to the line on the tractor marked P(from the PTO valve)
2.Connect the T port on the loader control valve to the line on the tractor marked T
3.Connect the remaining line from the control valve to the line on the tractor marked P1
( to the transmission housing)
►
►►
► DETACHING THE LOADER (LOADER VALVE OR LOADER CONNECTING PORT)
1.Detach the hydraulic hoses of loader
2.Assemble the cap (PF3/8) with pipe comp (PF3/8).
59
