Mahindra 4010 HST User Manual

SPECIFICATIONS
Model: 4010 HST
ENGINE
Four strokes, Indirect injection, water-cooled
Diesel Engine.
Model : 3B183LW (DAEDONG)
No. of cylinders : 3
Displacement : 1,826cm
3
Bore : 87 mm (3.43 in)
S
troke : 102.4 mm ( 4.03 in)
Compression Ratio : 22:1
Horse Power (HP) : 38/ 2700rpm
(Manufacturing rating)
Rated Speed : 2,600 rpm
High idle rpm : 2800 rpm
Low idle rpm : 1000 rpm
Fuel injection pump : Indirect
Cylinder sleeve : Dry
Air Cleaner : Dry Filter element, paper
element filtering
Firing order : 1-2-3
Exhaust Muffler : Horizontal Round.
Accelerator : Hand Accelerator
ELECTRICAL STARTING AND LIGHTING
Battery Capacity : 12V 80AH
Starter : Solenoid Engaged.
Key Start with Safety ,
starter switch
Alternator :12V 50A
Instrumentation : Hour meter, Tacometer
Fuel gauge.
Water Temperature Gauge.
Warming Lights.
Lighting: : Head lights,
Turn Signal Indicator Lamp,
Rear Parking, Brake Lamp
Tail Lamp
CLUTCH
Type : Damper
TRANSMISSION
Type : synchro mesh
No. of gears : 3 Speed forward,
3 Speed reverse
with high and low
selection lever with
HST unit
STEERING
Type : Hydraulic power
(Power steering)
POWER TAKE OFF
Mid mounted : 6 splines
Rear mounted : 6 splines
Diameter : 1 ⅜ in.
Standard PTO : Rear -540/2,775 engine rpm
Mid – 2000rpm
BRAKES
Foot operated, independent with provision of
inter lock for simultaneous operation.
A foot brake is fitted for parking.
Inner dia. : 160 mm (6.30 in)
Outer dia. : 210 mm (8.23 in)
Number of lining : 4 each side
Total brake thickness : 1.96 in
HYDRAULIC SYSTEM
3 Point linkage : Category 1
(Adjustable outside check chains)
77
