to make sense now? The 5-to-6-position GPS cable will plug the
6-position end into the GPS port, while the compass cable will
take either end of our 4-position cable (see Figure 5-6).
Figure 5-6. The two ports on the side of our GPS puck.
MAG Port
In case you haven’t
figured it out on your own, the
MAG port on the side of the GPS puck is labeled as
such because it is short for magnetometer. This is
the technical name of the sensor that provides our
compass functionality.
100 Make: Getting Started with Drones
