Manitou 280 TJ - Characteristics 260 TJ - 280 TJ

2-12
CHARACTERISTICS 260 TJ  280 TJ
LOAD SPECIFICATIONS UNIT 280 ATJ 260 TJ TOL ±
Lifting platform
Nominal capacity for indoor use Kg 240 / 350 400 -
Nominal capacity for outdoor use Kg 240 / 350 400 -
Maximum wind during outdoor use 45 -
Number of persons in the basket - 2 / 3 3 -
Turret rotation CONTINUOUS
Lifting platform unladen weight (actual / announced) Kg 16 550 / 16 650 16 380 / 16 450 -
Lifting platform unladen weight (min / max) Kg 16 300 / 16 650 16 130 / 16 480 -
Max permissible tilt ° 4 4 0.1
Traversable slope - commercial value % 40 40 2
Traversable slope - theoretical value % 34,5 34,5 -
Working speed Km/h 0.8 0.1
Transport speed (1) tortoise (slow speed) Km/h 2.5 0.2
Transport speed (2) ramp Km/h 2.5 0.2
Transport speed (3) hare (high speed) Km/h 4.7 0.2
Wheels
Tyre SOLIDEAL 385/45-28
Inflation / pressure bar 7.5
Overload radius, front/rear, transport position mm 500 / 504 520 / 532 5
Load on one front wheel (in transport position) Kg 5 500 5 675 10
Load on one rear wheel (transport position) Kg 2 800 2 550 10
Maximum load on one wheel, working position Kg 10 500 9 500
Contact surface on the ground (hard / soft ground) cm² 623 / 1 160 635 / 1 471
Surface penetration (hard / soft ground) daN/cm² 16,85 / 9,05 14,96 / 6,46
HYDRAULIC MOVEMENT (basket control) UNIT 280 ATJ 260 TJ TOL ±
Structure, telescope retracted
Raising unladen / laden s 45 / - 45 / - 1
Lowering unladen / laden s 42 / - 42 / - 1
Structure, telescope extended
Raising unladen / laden s 70 / - 70 / - 1
Lowering unladen / laden s 70 / - 70 / - 1
Telescope
Extended unladen / laden s 30 / - 30 / - 1
Retracted unladen / laden s 30 / - 30 / - 1
Pendular unit, telescope retracted
Raising unladen / laden s 22 / - 23 / - 1
Lowering unladen / laden s 18 / - 18 / - 1
Pendular unit, telescope extended
Raising unladen / laden s 30 / _ 1
Lowering unladen / laden s 25 / _ 1
Pendular unit telescope
Extended unladen / laden s 16 / _ 1
Retracted unladen / laden s 13 / _ 1
Turret rotation
Rotation 360°, telescope extended / retracted s 50 / 30 / 28 50 / 30 / 28 1
Basket rotation
Rotation over 180° s 14 14 2
647382 EN (01/02/2015)
