2-13
CHARACTERISTICS 260 TJ 280 TJ
DIMENSIONS UNIT 280 TJ 260 TJ TOL ±
Transport position
Width mm 2 430 1%
Length mm 11 355 10 840 1%
Height mm 2 750 1%
Length (truck transport) mm 8 040 8 000 1%
Height (truck transport) mm 2 750 1%
Floor / ground height, during transport mm 500 400 1%
Turret overlap mm 1 450 1%
Clearance under the chassis mm 430 2%
Clearance under the axle mm 375 2%
Max chassis clearance angle % 80 2%
INT / EXT 2-wheel drive gyration radius (measured) mm - - 3%
INT / EXT 4-wheel drive gyration radius (measured) mm 1 750 / 7 235 1 750 / 6 845 3%
Work Position
Working height mm 27 750 25 910 1%
Floor height mm 25 750 23 910 1%
Working offset (interior of basket + 500 mm) Abacus 1 mm 21 450 - Load 240 Kg 19 700 1%
Working offset (interior of basket + 500 mm) Abacus 2 mm 19 450 - Load 350 Kg - 1%
Floor height, basket at max offset mm 3 050 2 900 1%
Overhang under upper arm mm - - 1%
Pendular arm clearance angle + / - ° + 56,8 / - 62 + 70,3 / - 63 1%
Basket
External dimensions mm 2 300 x 900 1%
Floor area mm 2 235 x 840 1%
CAPACITY UNIT 280 TJ 260 TJ TOL ±
Hydraulic oil reservoir l 94 2
Diesel tank l 72 2
Engine oil sump l 9.5 2
Coolant circuit l 9 2
STANDARD EQUIPMENT UNIT 280 TJ 260 TJ TOL ±
Hour counter YES -
230V pre-configuration YES -
Diesel level proportional display YES -
Low fuel level / battery alarm YES -
Dead Man’s handle YES -
Toolbox in the basket YES -
User interface (diagnostic help) YES -
Oscillating axle YES -
OPTIONS UNIT 280 TJ 260 TJ TOL ±
Audible beep on all movements YES -
Rotating flashing light SERIE -
