2 - 16
CHARACTERISTICS
LOAD SPECIFICATIONS MAN' GO 12 TOL ±
Platform
Nominal capacity for use indoors (Wind 0 Km/h) Kg
230
-
Nominal capacity for use outdoors (Wind 45 Km/h) Kg -
No. of people in the basket during indoor use
2
-
No. of people in the basket during outdoor use
2
-
Lifting platform unladen weight Kg
4150
40
Max permissible tilt °
4
0,1
Traversable slope (+200 Kg) %
40
-
Work speed Km/h
1
0,1
Slow transport speed (1) Km/h
3,2
0,2
Ramp transport speed (2) Km/h
3,8
0,2
Fast transport speed (3) Km/h
5,2
0,2
Wheels
Front wheel radius under load (transport position) mm
352
5
Rear wheel radius under load (transport position) mm
352
5
Load on one front wheel (transport position) Kg
1142
20
Load on one rear wheel (transport position) Kg
933
20
Max load on one wheel Kg
2700
50
Contact surface on the ground (hard / soft ground) Cm²
180 - 417
10
Surface punch-through (hard / soft ground) daN/cm²
15 - 6,5
-
LwA acoustic pressure level db
100
-
HYDRAULIC MOVEMENT(basket control) MAN' GO 12 TOL ±
Arm Movement 3 (Telescope extend)
- Raising unladen / laden s
22
5
- Lowering unladen / laden s
22
5
Arm Movement 3 (Telescope Return)
- Raising unladen / laden s
19
5
- Lowering unladen / laden s
19
5
Telescope Movement
- Extended unladen / laden s
9
5
- Lowering unladen / laden s
9
5
Pendular arm movement
- Extended unladen / laden s
22
5
- Lowering unladen / laden s
24
5
Turret rotation
- Rotation 360° (Telescope extended / Retracted) s
80
5
Basket rotation
- Rotation over 125° (58.5° left + 66.5° right) s
10
5
INTERNAL COMBUSTION ENGINE MAN' GO 12 TOL ±
Type
KUBOTA D1105- E2B
Fuel
Diesel
-
No. of cylinders
3
-
Cubic capacity Cm3
1 123
-
Idling speed, unladen (factory settings) tr/mn
1300
20
Max engine revs, unladen (factory settings) tr/mn
3000
20
Nominal power kW
19
Net power intermittent kW
16,6
-
Max torque Nm
71
-
Unladen weight Kg
93
5
Air filtration µm
-
-
Type of cooling
water
-
Fan
suction
647533 (09/10/2015)
MAN'GO 12
