SCREEN DISPLAY - DESCRIPTION OF THE PAGES
1 - PRESENTATION PAGE
When you switch on, an initialisation page appears briefly on the screen and then the pre-heating page
is displayed.
2 - PRE-HEATING PAGES
The Pre-heating page is displayed for the whole of the adjustable pre-heating period and the bar graph
increases in increments in proportion to the pre-heating time elapsed.
3 - STAR-UP PAGES
When the pre-heating time has expired (bar graph complete), ‘OK’ is displayed,
followed by the Work page or, where applicable, the Fault page.
A: Network search
B: Start-up OK
4 - WORK PAGES
Working page from the base with fault present.
Working page from the base with engine oil pressure fault present.
2 - 40
647533 (09/10/2015)
MAN'GO 12
