Manitou MAN'GO 12 User Manual

3 - 8
MAINTENANCE TABLE
t
IMPORTANT
t
(1): MANDATORY 500 HOUR OR 6 MONTH SERVICE. This service must be carried out after approximately the first 500 hours of operation or within the 6 months following
the start-up of the machine (whichever occurs first).
(2): The internal-combustion engine oil and its oil filter must be replaced after the first 50 hours of operation, and subsequently every 500 hours of operation.
(3): Contact your dealer.
A = ADJUST, C = CHECK, G = GREASE, N = CLEAN,
P = BLEED, R = REPLACE, V = DRAIN
PAGE (1)
DAILY OR EVERY 10
HOURS OF SERVICE
EVERY 50 HOURS
OF SERVICE
EVERY 250 HOURS
OF SERVICE
EVERY 500 HOURS
OF SERVICE
OR EVERY 6 MONTHS
EVERY 1000 HOURS OF
SERVICE OR EVERY ONE YEAR
EVERY 2000 HOURS OF
SERVICE OR EVERY TWO
YEARS
EVERY 4000 HOURS OF
SERVICE
OCCASIONALLY
ENGINE
- Engine oil level (2) 3-11/3-26 V/R C V/R
- Cooling liquid level 3-11/3-32 C C V/R
- Fuel level 3-11 C C
- Fuel circuit hose 3-14/3-34 C P
- Radiator core 3-15 N N
- Dry air filter cartridge 3-15/3-24 R N R
- Alternator/crankshaft/fan belt tension 3-14/3-26 C/A C/A C/A R
- Cooling circuit 3-21 C C
- Fuel filter 3-22 N N
- Fuel filter cartridge (2) 3-16/3-24 R R R
- Fuel pre-filter 3-24 R R
- Engine oil filter (2) 3-27 R R
- Fuel tank 3-30 V/N
- Dry air filter safety cartridge 3-30 R
- Engine silentblocks 3-31 C (3)
- I.C. engine rates 3-31 C (3)
- Valves clearances 3-31 C (3) C (3)
- Injectors 3-33 (3)
- Radiator 3-33 C (3)
- Water pump and thermostat 3-32 C (3)
- Alternator and starter 3-32 C (3)
- Fuel injection pressure 3-32 C (3)
- Turbocompressor 3-33 C (3)
- Injection pump 3-33 C (3)
TRANSMISSION
- Brakes 3-12/3-26 C C C
- Direction pivots 3-14 C
- Hydrostatic transmission circuit pressure 3-31 C (3)
- Start of hydrostatic transmission control 3-31 C/A (3)
TYRES
- Condition of the wheels and tyres 3-12 C C
- Tightness of the wheel nuts 3-18 C
- Wheels 3-34 R
LIFTING STRUCTURE
- Telescope adjustment 3-18 C
- Brake reducer on the turret reduction gear 3-18/3-28 C V/R
- Tightness of the bolts on the turret rotation motor 3-26 C
HYDRAULIC SYSTEM
- Hydraulic oil 3-12/3-25 C C V/R
- Hydrostatic transmission oil filter cartridge 3-24 R R
- Auxiliary oil filter cartridge 3-25 R
- Condition of the hoses 3-25 C
- Hydraulic circuit strainer 3-31 N
- Hydraulic movement speeds 3-31 C (3)
- Condition of the cylinders (leaks, rods) 3-30 C (3)
- Hydraulic oil reservoir 3-32 N
- Hydraulic circuit pressures 3-32 C (3)
- Hydraulic circuit flows 3-32 C (3)
- Manual emergency pump 3-18 C
647533 (09/10/2015) MAN'GO 12
