2 - 50
DESCRIPTION AND USE OF THE OPTIONS
1 - SAFEMANSYSTEM
The SafeManSystem option is a system used to disable all of the basket control panel
controls when activated by the lifting platform user.
OPERATION
• Each time the lifting platform is switched on, a system test is performed:
there is a beep and the blue warning light flashes.
• If the pressure-sensitive edge is pressed, the system cuts all of the lifting
platform controls. The blue warning light and an audible alarm are activated.
• If the user releases the pressure-sensitive edge:
• By pressing the nacelle “OFF” rearming button once, the user can regain
control of the nacelle controls. The blue warning light and the audible alarm
are turned off.
• If the user continues to press on the pressure-sensitive edge:
• By pressing the lifting platform “OFF” rearming button once, the user can
regain control of the lifting platform controls. The blue warning light and the
audible alarm are turned off when the user releases the pressure-sensitive
edge.
t
IMPORTANT
t
When the "retracting telescope" option is activated, the telescope retracts automatically when the
SafeManSystem is triggered.
1
2
2 - GENERATOR
Precautions for use for the operator when using lifting platforms fitted with this option:
t
IMPORTANT
t
Do not connect electrical equipment that is not fitted with a shut-off switch. Voltage spikes may occur when
starting the generator.
ON: Use the switch on the basket console to activate the generator.
OFF: Press the button to activate or deactivate the generator
The generator stops temporarily during a hydraulic movement (e.g.: an arm movement).
1
647533 (09/10/2015)
MAN'GO 12
