Manitou MC 18-2 D K ST5 S1 User Manual

SPECIFICATIONS MC 18-4...
NOTE: The specifications given are not binding on the manufacturer and can be modified without prior notification.
DESIGNATION
1.1 Manufacturer MANITOU
1.2
Model type / Serial no. MC 18-4 D K ST5 S1
1.3 Propulsion: battery, diesel, petrol, LPG, mains Diesel
1.4
Type of operation: manual, pedestrian, standing, seated Seated
1.5
Rated capacity/load on forks (basic capacity) Q (t) 1.8
1.6 Centre of gravity of load c (mm) 500
1.8
Distance from the load bearing surface to the centre of the
front axle
x (mm) 616
1.9
Wheelbase y (mm) 1900
WEIGHT
2.1 Weight of truck in working order kg 3547
2.2
Front axle load laden kg 4500
2.2.1
Rear axle load laden kg 840
2.3 Front axle load unladen kg 1647
2.3.1
Rear axle load unladen kg 1900
RUNNING CARRIAGE
3.1
Tyre equipment
bandage (V), super-elastic (SE), pneumatic (L)
L
3.2
Size of front wheels “ or mm 12,5/80-18/12 SL R4
3.3 Size of rear wheels “ or mm 27x10-12 SKS
3.5
Number of front wheels (x = drive wheel) 2x
3.5.1
Number of rear wheels (x = drive wheel) 2x
3.6
Front track (middle of wheels) b10(mm) 1159
3.7
Rear track (middle of wheels) b11(mm) 1176
DIMENSIONS
4.1 Tilt of mast forward α(°) 12
4.1.1
Tilt of mast backward β(°) 10
4.2
Height of mast lowered h1(mm) 2348
4.3
Normal free lift h2(mm) 85
4.4
Lift height h3(mm) 3300
4.5 Height of extended mast h4(mm) 4018
4.7
Standard height of the overhead guard/cab / cab with air
conditioning
h6(mm) 2155
4.7
Lowered height of the overhead guard, cab or cab with air
conditioning
h6*(mm) 1990
4.8
Height of seat h7(mm) 1094
4.12
Height of towing coupling h10(mm) -
4.19
Total length l1(mm) 4100
4.20
Length of forks at heel l2(mm) 2950
4.21 Overall width b1(mm) 1450
4.22
Section of fork arms s(mm) 35
4.22.1
Width of fork arms e(mm) 100
4.22.2 Length of fork arms l(mm) 1150
4.23
Fork carriage (in accordance with standard DIN 15173 A/B) FEM 2A
4.24
Width of fork carriage (with load backrest) b3(mm) 1260
4.31
Ground clearance of mast unladen m1(mm) 300
4.32
Ground clearance at centre of wheel-base unladen m2(mm) 310
4.33
Aisle width for 1000x1200 pallet widthways Ast(mm) 5336
4.34
Turning radius Wa(mm) 3370
2-12
647837 M1 (A052020) MC 18-2/18-4 D K ST5 S1
