MULTIFUNCTION SCREEN
FORWARD/NEUTRAL/REVERSE INDICATOR
 FORWARD/NEUTRAL/REVERSE GEAR SELECTION
INDICATOR LIGHTS AND WARNING INDICATORS
 LIGHTING, INDICATOR AND HORN SWITCH
 SWITCHES
MAIN BEAM INDICATOR
 SWITCHES
GENERAL FAULT INDICATOR
The indicator lamp is accompanied by an error code on the display.
Contact your dealer.
500H MAINTENANCE INDICATOR
The indicator lamp is accompanied by the time remaining or the time elapsed on the display. (3-MAINTENANCE).
NOTE: The maintenance key appears 50 hours before the deadline and generates an audible signal when the lift truck is
started.
To display this time again, use the validation button
.
ENGINE PREHEAT INDICATOR
When the ignition is on, this indicator lamp comes on and indicates that engine preheating is in progress.
When the lamp goes out, the engine can be started.
TRANSMISSION OIL TEMPERATURE FAULT INDICATOR
If the indicator lamp comes on, stop the engine immediately and look for the cause (leak, etc.).
TRANSMISSION OIL PRESSURE FAULT INDICATOR
If the indicator lamp comes on, stop the engine immediately and look for the cause (leak, etc.).
A - ENGINE COOLANT TEMPERATURE LEVEL
10-level LED display from 0 to 120° and indicator
1
st
(
*
)
LEDs +
... -> 0° Not used
Wait for the temperature to increase before
using
1
st
to 3
th
LEDs 0° -> 55° Moderate use Wait till the temperature rises for optimum use
1
st
to 8
th
LEDs 55° - 105° Normal use
1
st
to 9
th
LEDs +
(
*
)
+
105° -> 110° Usage stopped Monitor the temperature
1
st
to 9
th
+ 10
th
(
*
)
LEDs +
(
*
)
+
110° -> 120° Stop the engine immediately Find the cause of the overheating
1
st
(
*
)
to 10
th
(
*
)
LEDs +
(
*
)
+
120° -> ... Stop the engine immediately Consult your dealer
(*) flashing
B - FUEL LEVEL
LED display with 10 fuel tank levels
1
st
(
*
)
LED + +
Limited usage time (Reserve) Fill the fuel tank
(
*
)
+
Usage time finished Fill the fuel tank quickly
1
st
(
*
)
to 10
th
(
*
)
LEDs +
(
*
)
Fault Consult your dealer
(*) flashing
2-23
RazNav
C
D
A
B
647837 M1 (A052020) MC 18-2/18-4 D K ST5 S1
