Manitou MC 18-2 D K ST5 S1 - Cab Option

HALF-DOOR ON RIGHT-HAND DOOR
- Lower the latch A to open the half-door.
NOTE: The half-door must be:
• Either closed.
• Either completely open and locked on the door arrester system.
SLIDING WINDOWS ON LEFT-HAND DOOR
- Press the latches A and slide the windows.
DOOR RELEASE HANDLES
- Pull on the handle A to release and close the door.
37 - CAB OPTION
DOOR OPENING HANDLES
- Insert the ignition key into lock A to lock or unlock
the cab.
- Pull on the handle B or C to open the door.
NOTE: The door must be:
• Either closed.
• Either completely open and locked on the
door arrester system.
2-44
A
A
A
A
B
A
C
647837 M1 (A052020) MC 18-2/18-4 D K ST5 S1
