CLEAN Dry air filter cartridge
Pre-filtration cartridges are available for use in very dusty atmospheres (FILTER CARTRIDGES AND BELTS). In this case, the
cartridge checking and cleaning interval must be reduced.
IMPORTANT
If the clogging indicator light comes on, this operation should be performed as soon as possible (maximum 1 hour).
Never operate the lift truck with the air filter removed or damaged.
Clean the cartridge in a clean place away from the air filter unit.
Protect your eyes during this operation.
Never clean the cartridge by tapping it on a hard surface.
Never wash the dry air filter cartridge.
Never clean the air filter safety cartridge. Replace it with a new one if it is clogged or damaged.
- For the dismantling and refitting of the cartridge (1000H: REPLACE Air filter cartridge).
- Leave the safety cartridge in place.
- Clean the filter cartridge from inside to outside using a compressed air jet (max. 2 bar), maintaining a safe distance (min.
30mm) to avoid damaging the cartridge.
- Use a damp, clean, lint-free cloth to clean the surface of the cartridge seal.
- Lubricate the surface of the seal with a silicone lubricant (Part No. MANITOU: 479292).
- Check visually the outer condition of the air filter and its attachments.
- Also check the condition and attachment of the hoses.
CLEAN Radiator harness
IMPORTANT
In a polluting atmosphere, clean the radiator core every day.
Do not use a water jet or high pressure steam as this could damage the fins.
Wear a mask and protective goggles for cleaning.
- Remove the access panel 1.
- Using a soft cloth, clean the core in order to remove as much dirt as possible.
- Clean the radiator using a compressed air jet aimed from the engine towards the
radiator, in the opposite direction to the cooling air flow.
- Refit access panel 1
1
3 - 16
647837 M1 (A052020)
MC 18-2/18-4 D K ST5 S1
