HYDRAULIC CONTROLS WITH MORE THAN ONE HYDRAULIC ATTACHMENT
C1-OPTIONAL 3RD HYDRAULIC LINE (AUX.1)
C2-OPTIONAL 3RD HYDRAULIC LINE (AUX.1)
D1-OPTIONAL 4TH HYDRAULIC LINE (AUX.2)
D2-OPTIONAL 4TH HYDRAULIC LINE (AUX.2)
TILTABLE CARRIAGE option
C1-OPTIONAL 3RD HYDRAULIC LINE (AUX.1 - TILTABLE CARRIAGE)
C2-OPTIONAL 3RD HYDRAULIC LINE (AUX.1 - TILTABLE CARRIAGE)
D1-OPTIONAL 4TH HYDRAULIC LINE (AUX.2)
D2-OPTIONAL 4TH HYDRAULIC LINE (AUX.2)
E+ D1- OPTIONAL 5TH HYDRAULIC LINE (AUX.3 or HYDRAULIC
ATTACHMENT LOCKING)
E+ D2- OPTIONAL 5TH HYDRAULIC LINE (AUX.3 or HYDRAULIC
ATTACHMENT LOCKING)

IMPORTANT

If the attachment's hydraulic locking equipment is used, make sure that the attachment is properly
locked onto the tiltable carriage before use.
2-39
D1
D2
C1
C2
D1
D2
C1
C2
E
647837 M1 (A052020) MC 18-2/18-4 D K ST5 S1
