(25/11/2011)10-07-M184EN
10
22 ENGINE REFIT
F - REINSERTING THE ALTERNATOR
Reposition the alternator (Ref. 1).
Reconnect the electric wires (Ref. 2 and 3) for connection to
the alternator (Ref. 1).
Block the alternator (Ref. 1) to the engine by means of the
screws (Ref. 4).
1
1
1
2
3
4
