Manitou MHT 10225 - Removing the Engine

(05/06/2012) 10-06-M184EN
10
21ENGINE REMOVAL
REMOVING THE ENGINE
Disconnect the plug (Ref. 1) from the engine control unit (Ref. 2).
Disconnect all the electrical connections (Ref. 3) from the
alternator (Ref. 4).
Disconnect all the electrical connections (Ref. 5) from the starter
motor (Ref. 6).
Disconnect the temperature sensor (Ref. 8) from the thermostatic
valve (Ref. 7).
1
2
3
3
4
5
6
7
8
