CLEAN Dry air filter cartridge
When used in very dusty atmospheres there are pre-filtration elements (eFILTER CARTRIDGES AND BELTS). The cartridge
checking and cleaning interval must also be reduced.
t
IMPORTANT
t
If the clogging indicator light comes on, this operation should be performed as soon as possible (maximum 1 hour).
Never operate the lift truck with the air filter removed or damaged.
Maintain a safety distance of 30 mm between the jet of air and the cartridge to avoid tearing or piercing the cartridge.
The cartridge must not be blown through close to the air filter casing.
Never clean the cartridge by tapping it on a hard surface.
Protect your eyes during this operation.
Never wash a dry air filter cartridge.
Never clean the safety cartridge located inside the filter cartridge. Change it for a new one if it is clogged or damaged.
- For the dismantling and refitting of the cartridge (e1000H: REPLACE Air filter cartridge).
- Clean the filter cartridge using a compressed air jet (max. pressure3 bars) directed from the top to the bottom and from
the inside towards the outside at a minimum distance of30 mm from the cartridge wall.
- Cleaning is completed when there is no more dust on the cartridge.
- Clean the cartridge seal surface with a damp, clean lint-free cloth and grease with a silicone lubricant (MANITOU part
no.:479292).
- Check visually the outer condition of the air filter and its mounts. Verify the condition of the hoses and their mounts also.
CLEAN Condenser harness (Air conditioning OPTION)
t
IMPORTANT
t
In a polluting atmosphere, clean the radiator core every day.
Do not use a water jet or high-pressure steam as this could damage the condenser fins.
- Remove the protective grid1 and clean it if necessary.
- Visually check whether the condenser is clean and clean it if necessary.
- Clean the condenser using a compressed air jet aimed in the same direction as the
air flow.
- Clean with the fans running for best results.
1
3 - 19
