21 - FUNCTION FILES
These files contain the description of the hydraulic controls and the load charts for
the attachments used on the lift truck.
22 - LEVEL INDICATOR
Enables the operator to check that the lift truck is in the horizontal position.
A1-LIFTING
A2-LOWERING
B1-EXCAVATION
B2-DUMP
C1-TELESCOPE EXTENSION
C2-TELESCOPE RETRACTION
D1-ATTACHMENT
D2-ATTACHMENT
E-BOOM ELECTRICAL PREDISPOSITION (OPTION)
BOOM HEAD ELECTROVALVE (OPTION)
(
eDESCRIPTION AND USE OF THE OPTIONS).
F1-LOWERING LEFT STABILISER
MT1033...
F2-LIFTING LEFT STABILISER MT1033...
G1-LOWERING RIGHT STABILISER MT1033...
G2-LIFTING RIGHT STABILISER MT1033...
NOTE: The stabilisers can only be raised after the jib has been retracted.
2 - 51
20
21
A1
A2
B2
B1
C1
C2
D1
D2
E
F1
G1
F2
G2
647776 (28/02/2020) MT 733/933/1033 EASY 75D ST5 S1
