Manitowoc Grove RT540E Service Maintenance Manual

Published 4-20-2015, Control # 502-01 2-69
RT540E SERVICE MANUAL HYDRAULIC SYSTEM
2
GROVE
3. Install the O-ring and backup ring onto the outside of the
head.
FIGURE 2-38
6722
11
10
7
6
5
4
3
8
9
2
1
Item Description
1 Barrel
2Piston
3 Head
4 Wear Ring
5 Setscrew
6O-ring
Item Description
7 Piston Ring Seal
8O-ring
9 Backup Ring
10 Seal Rod Ring
11 Wiper Ring
Reference Only
