Manitowoc Grove RT540E - Outriggers

Published 4-20-2015, Control # 502-01 9-13
RT540E SERVICE MANUAL LUBRICATION
9
GROVE
Item
Lube Point
Description
Figure
No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Outriggers
18 Outrigger Beams Figure 9-5
EP-MPG
Extreme
Pressure
Multipurpose
Grease
A6-829-003477
--- 50 hours or 1 week
Brush lubricant on
bottom of outrigger
beams
19
Jack Cylinder
Support Tubes
Figure 9-5
EP-MPG
Extreme
Pressure
Multipurpose
Grease
A6-829-003477
--- 50 hours or 1 week
Brush lubricant on
OD of jack cylinder
barrel and wear
band before
installing jack
cylinders
51
Jack Cylinder
Barrels
Figure 9-5
EP-MPG
Extreme
Pressure
Multipurpose
Grease
A6-829-003477
--- 50 hours or 1 week
Brush lubricant on
OD of jack cylinder
support tubes (4)
places before
installing jack
cylinders
Reference Only
