SWING SYSTEM RT540E SERVICE MANUAL
6-2 Published 4-20-2015, Control # 502-01
FIGURE 6-1
6713
11
9
8
12
1
13
2
5
3
4
7
6
10
Item Description
1Plug
2Plug
3Plug
4 Elbow
5Pipe
6 Breather
7Plug
Item Description
8 Dipstick
9 Breather
10 Plug
11 Motor
12 Gearbox and Brake
13 Pinion
Reference Only
