ELECTRIC SYSTEM RT540E SERVICE MANUAL
3-16 Published 4-20-2015, Control # 502-01
Appendix A: Crane Control System (CCS) Fault Codes
There are four codes for every fault in the Crane Control
System (CCS) diagnostic. The Component Code number
informs the operator which component is in fault mode; the
Condition Code explains the actual malfunction; the Device
Code indicates which module contains the fault; and the
Index Code reveals the type of fault. For example, a code
reading “7111. 2. 0. 129” correlates to “RCL Display”, “Cable
Break”, “SCMO”, “CANbus 1”. This means the RCL display
CANbus cable to the SCMO module is broken.
Component Codes
Fault Code Component Description
5000 Key switch On input
5001 Key switch Accessory input
5002 Key switch Start input
5003 Horn switch input
5005 Transmission Forward input
5006 Transmission Neutral input
5007 Transmission Reverse input
5008 Transmission 1st gear input
5009 Transmission 2nd gear input
5010 Transmission 3rd gear input
5011 Transmission 4th gear input
5012 Transmission 5th gear input
5013 Transmission speed gears (all)
5014 Transmission direction gears (all)
5015 Turn Signal left input
5016 Turn Signal right input
5017 Headlights input
5018 Marker lights input
5019 Hazard lights input
5020 Parking light switch
5021 Fog tail light switch
5022 Fog light switch
5023 Low beam headlight switch
5024 High beam headlight switch
5025 Windshield wiper low speed input
5026 Windshield wiper high speed input
5027 Windshield washer spray input
5028 Windshield wiper intermittent input
5030 Engine speed increment switch input
5031 Engine speed decrement switch input
5032 Rear steer left switch input
