RT540E SERVICE MANUAL LUBRICATION
9
GROVE
Item
Lube Point
Description
Figure
No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Turntable
20
Turntable Gear
Box
Figure 9-6
GL-5
Extended
Service Interval
Gear Lubricant
A6-829-012964
4.0 l
4.25 qt
• Check and fill every
50 hours
• Drain and fill after
first 250 hours and
every 500 hours or
12 months thereafter.
Use dipstick. If no
dipstick, fill to top of
case.
21
Turntable Gear
and Drive Pinion
Figure 9-6
EP-OGL
Open Gear
Lubricant
A6-829-102971
Coat all
teeth
500 hours or 6 months Spray on
21a
Turntable Swivel
Lock Pin
Not shown
EP-OGL
Open Gear
Lubricant
A6-829-102971
Coat pin 500 hours or 6 months Spray on
22
Turntable
Bearing
Figure 9-6
EP-MPG
Extreme
Pressure
Multipurpose
Grease
A6-829-003477
Until
grease
extrudes
the whole
circumfer-
ence of the
bearing
500 hours or 6 months
2 grease fittings at
the front of the
turntable
NOTE: Rotate the turntable 90° and apply grease to fittings. Continue rotating 90° and grease the fittings until the whole
bearing is greased.
