Manitowoc Grove RT540E Service Maintenance Manual

ELECTRIC SYSTEM RT540E SERVICE MANUAL
3-30 Published 4-20-2015, Control # 502-01
7090 Simulated Joystick
7091 Left joystick
7092 Right joystick
7093 Left joystick
7100 Remote Control -or- Slew Angle Sensor (default node ID)
7101 MMI Left
7102 MI Right
7106 External Light Tower
7108 Service Software
7109 Outside Light bar
7111 RCL display
7112 Operating display
7113 Carrier Display
7119 Jogdial
7123 Inside Light bar
7124 Cranestar
7129 J1939 Communications
7400 Engine RPM speed sensor
7401 Alternator Charge Frequency input
8000 RCL software
8001 Error List
8002 Operating system task 1
8003 Operating system task 2
8004 Operating system task 3
8005 Operating system task 4
8006 Operating system task 5
8007 Speed limit software
8008 RCL load charts
8009 AddReadSDO software function
8010 AddWriteSDO software function
8011 Telescoping software
8012 Interpolator / CCM closed loop current control
8013 Pinning program
8014 Slewing control system
8015 Derricking control system
8016 Main Hoist control system
8017 Aux Hoist control system
8100 Main Software Program
Fault Code Component Description
Reference Only
