Manitowoc Grove RT540E Service Maintenance Manual

Published 4-20-2015, Control # 502-01 3-31
RT540E SERVICE MANUAL ELECTRIC SYSTEM
3
GROVE
8400 Eeprom
8401 CPU watchdog
8402 Data Flash
8600 RCL Boom Length
8601 RCL Slewing Range
8602 RCL Outrigger
8603 RCL Jib
8700 Telescoping Length Sensor Comparison
8701 Pinning Proxy Switches Left
8702 Pinning Proxy Switches Right
8900 Engine Type Selection (eeprom setting)
10100 Proximity Sensor Drum 0 (A)
10101 Proximity Sensor Drum 0 (B)
10102 Proximity Sensor Drum 1 (A)
10103 Proximity Sensor Drum 1 (B)
10104 Proximity Sensor Drum 2 (A)
10105 Proximity Sensor Drum 2 (B)
10106 Proximity Sensor Drum 3 (A)
10107 Proximity Sensor Drum 3 (B)
10108 Proximity Sensor Drum 4 (A)
10109 Proximity Sensor Drum 4 (B)
10110 Proximity Sensor Drum 5 (A)
10111 Proximity Sensor Drum 5 (B)
10112 Proximity Sensor Drum 6 (A)
10113 Proximity Sensor Drum 6 (B)
10114 Proximity Sensor Drum 7 (A)
10115 Proximity Sensor Drum 7 (B)
10116 Proximity Sensor Drum 8 (A)
10117 Proximity Sensor Drum 8 (B)
10118 Proximity Sensor Drum 9 (A)
10119 Proximity Sensor Drum 9 (B)
10120 Luffing Jib Min
10121 Luffing Jib Max
10123 Fixed Jib Confirm
10125 Boom Strap Load Cell Right
10126 Boom Strap Load Cell Left
10130 Proximity Sensor Output (V+) Drum 0
10131 Proximity Sensor Output (V+) Drum 1
Fault Code Component Description
Reference Only
