ELECTRIC SYSTEM RT540E SERVICE MANUAL
3-32 Published 4-20-2015, Control # 502-01
10132 Proximity Sensor Output (V+) Drum 2
10133 Proximity Sensor Output (V+) Drum 3
10134 Proximity Sensor Output (V+) Drum 4
10135 Proximity Sensor Output (V+) Drum 5
10136 Proximity Sensor Output (V+) Drum 6
10137 Proximity Sensor Output (V+) Drum 7
10138 Proximity Sensor Output (V+) Drum 8
10139 Proximity Sensor Output (V+) Drum 9
10140 Boom Strap Load Cell Output (V+)
10141 Lower/Upper Boom Point A2B Slow Output (V+)
10142 Lower/Upper Boom Point A2B Stop Output (V+)
10143 Luffing Jib Max Output (V+)
10144 Luffing Jib Min Output (V+)
Fault Code Component Description
